"Right angle drive" by EDV - 20/01/2012
38.390 bytes - 144 parts
Description
This is one classic curious mechanical device which transmits rotation at right angle without using gears. Its concept is described in the Standard Mechanism's manuals.
Download modelDownload model (.mdl)


1 agual on 22/01/2012 16:45:12 said

A video of a smaller version of this mechanism can be seen at
http://www.youtube.com/watch?v=0Pqah1Sg4-w
