"Radial Crane" by Ricky Mekano - 15/12/2017
156.973 bytes - 578 parts
Description
From Crane 1978's Construction Set model books.
The tower rotation was impossible in real, so I set 12V moto-reductor with boom wheels with gears: It works!
My 12Vac stepper motor drives winch. Meccano 6V moto-reductor drives trolley.
I'm starting to use flexible plates for housing.
I know, this model is not so fantastic than my previous Construction Site Crane …
Download modelDownload model (.mdl)


1 Ricky Mekano, the author of the model, on 15/12/2017 17:38:53 said

You can see now this model working on my Facebook page: https://www.facebook.com/rick.demil/videos/912062578958894/?l=3207527628243655985
Enjoy!
2 Ricky Mekano, the author of the model, on 16/12/2017 11:47:18 said

Here is the video on VIMEO: https://vimeo.com/247599975
