"Facel-Véga HK500" by PMcam235 - 21/03/2020
657.361 bytes
Description
Famous luxury French sport car from Facel-Véga at scale 1/9.
Featured in details in CAM Magazine #119 (Q3 2012) and CQ #106 (Dec. 2014).

Notice that owing to VM limitations, the front longitudinal torsion bars and rear transversal torsion bars are not shown properly tied to their extreme bolts, as it is not possible to show them twisted.

Notice also (additional picture) that the door sliding latch mechanism is set in place with a rubber band as per the photo.

Additional files
File detailsUpload date
.JPG file  door latch rubber band [ .JPG - 382.438 bytes ]
position of the rubber band acting as a spring for the sliding latch
21/03/2020 22:12:05 Download
.JPG file  vue générale [ .JPG - 431.015 bytes ]
real model, overall view
21/03/2020 22:13:53 Download
Download modelDownload model (.mdl)


1 Krypta on 22/03/2020 11:38:58 said

really impressive model, great job with all those bendings, thank you for sharing
