"Snub cube" by EDV - 17/02/2015
82.437 bytes - 304 parts
Another semi regular Archimedian geometric solid having 32 identical equilateral triangular faces and 6 square faces.
I did not use square flat plates #72 in the square faces due to diffence of lenght of the prolongued edges of the equilateral triangular plates part # 76 that creates a space larger than the square flat plate # 72
Download modelDownload model (.mdl)
